Idle-Gated Split-Flaps, Qt Page Caches, and the 3-Row Textual LED Billboard

  OPTION 1: TEXTUAL #ticker_bar IN logs.py (Unix File-Backed Widget)
  ┌──────────────────────────────────────────────────────────────────────┐
  │ Header: Web Bot AI Observatory — https://mikelev.in                  │
  ├──────────────────────────────────────────────────────────────────────┤
  │ #log_stream (height: 1fr — auto-shrinks by 1-3 rows automatically)   │
  │ [16:30:01] [mikelev.in] 66.249.*.* GET /futureproof/... [200] 🟠     │
  ├──────────────────────────────────────────────────────────────────────┤
  │ #ticker_bar: 📡 LIVE: Reading "EO 14434, Duck Decoys & Neovim..." ◄──┼── Reads /tmp/honeybot_ticker.txt
  ├───────────────────────────────────┬──────────────────────────────────┤   (mtime check every 0.1s)
  │ ⚡ DOM HYDRATION TRAPDOOR         │ 🧠 RFC 9110 MARKDOWN NEGOTIATORS │
  └───────────────────────────────────┴──────────────────────────────────┘

! book
! markov
! rgxc 50
! ssh -o ConnectTimeout=5 mike@[REDACTED_IP] 'free -m | head -2; for b in obs mpv feh alacritty dzen2 lemonbar; do printf "%s=%s " "$b" "$(command -v $b >/dev/null && echo YES || echo NO)"; done; echo ""; python3 -c "import sys, importlib.util as u; print(*(f\"{m}={u.find_spec(m) is not None}\" for m in sys.argv[1:]))" textual rich PyQt6 PySide6 tkinter' && (rg -q 'ticker_bar' remotes/honeybot/scripts/logs.py && echo "TICKER_IN_LOGS_PY" || echo "TICKER_NOT_IN_LOGS_PY")
flake.nix
nixops.sh
scripts/articles/common.py
remotes/honeybot/scripts/stream.py
remotes/honeybot/scripts/logs.py

Review the Honeybot RAM and package probe receipt, and let's decide: should we slice a file-driven `#ticker_bar` (reading `/tmp/honeybot_ticker.txt` with a default live telemetry/article marquee and a `ytticker` CLI helper on Prime) directly into `logs.py` between `#log_stream` and `#intelligence_panel` (or at the very bottom of the HUD)?

# # Context 1
# ! book
# ! markov
# ! rgxc 50
# flake.nix
# prompt_foo.py
#
# # HOME-HOSTED (NOT BEHIND CDN) NGINX WEBSERVER HONEYBOT AI OBSERVATORY
# nixops.sh
# remotes/honeybot/hooks/post-receive
# remotes/honeybot/nixos/configuration.nix
# remotes/honeybot/scripts/stream.py
# remotes/honeybot/scripts/score.py
# remotes/honeybot/scripts/card.py
# remotes/honeybot/scripts/forest.py
# remotes/honeybot/scripts/test_forest.py
# remotes/honeybot/scripts/logs.py
# remotes/honeybot/scripts/content_loader.py
# remotes/honeybot/scripts/db.py

# Context 2
! book
! markov
! rgxc 50
! ssh -o ConnectTimeout=5 mike@[REDACTED_IP] 'free -m | head -2; for b in obs mpv feh alacritty dzen2 lemonbar; do printf "%s=%s " "$b" "$(command -v $b >/dev/null && echo YES || echo NO)"; done; echo ""; python3 -c "import sys, importlib.util as u; print(*(f\"{m}={u.find_spec(m) is not None}\" for m in sys.argv[1:]))" textual rich PyQt6 PySide6 tkinter' && (rg -q 'ticker_bar' remotes/honeybot/scripts/logs.py && echo "TICKER_IN_LOGS_PY" || echo "TICKER_NOT_IN_LOGS_PY")
flake.nix
nixops.sh
scripts/articles/common.py
remotes/honeybot/scripts/stream.py
remotes/honeybot/scripts/logs.py

  ┌──────────────────────────────────────────────────────────────────────┐
  │ #log_stream (height: 1fr)                                            │
  │ [17:05:12] [mikelev.in] 66.249.*.* GET /futureproof/... [200] 🟠     │
  ├── 📡 LIVE SIDE-BAND TICKER (ytticker / /tmp/honeybot_ticker.txt) ────┤
  │ █ █ ███ █ █   ██▄ ▄█▄ ██▄ ███   ▄██ █ █ ██▄ ███   ▄█▄ █   █ ▄█▄ █ █  │
  │ ███ ██   █    █ █ █ █ █ █  █    ▀█▄ █ █ ██▀ ██    ███ █ █ █ ███  █   │
  │ █ █ ███  █    ██▀ ▀█▀ █ █  █    ██▀ ▀█▀ █ █ █     █ █  ▀▄▀  █ █  █   │
  ├───────────────────────────────────┬──────────────────────────────────┤
  │ ⚡ DOM HYDRATION TRAPDOOR (13)    │ 🧠 RFC 9110 MARKDOWN READERS (13)│
  └───────────────────────────────────┴──────────────────────────────────┘

! python3 -c 'import pathlib, subprocess; l = "YES" if "ticker_bar" in pathlib.Path("remotes/honeybot/scripts/logs.py").read_text() else "NO"; c = "YES" if "\"ticker\"" in pathlib.Path("scripts/articles/common.py").read_text() else "NO"; r = subprocess.run(["ssh", "-o", "ConnectTimeout=5", "mike@[REDACTED_IP]", "rg -q ticker_bar ~/www/mikelev.in/scripts/logs.py && echo YES || echo NO"], capture_output=True, text=True).stdout.strip() or "ERR"; print(f"LOCAL_LOGS_TICKER={l} | LOCAL_COMMON_TICKER={c} | REMOTE_LOGS_TICKER={r}")'
flake.nix
scripts/articles/common.py
remotes/honeybot/scripts/logs.py

Target: remotes/honeybot/scripts/logs.py
[[[SEARCH]]]
# --- Configuration ---
STRIP_MOZILLA_PREFIX = False  # Set to True to save space in bottom panels
HUD_TABLE_ROWS = 15           # Visible data rows in both bottom HUD tables (tuned from 17 to 15)
HUD_PANEL_HEIGHT = HUD_TABLE_ROWS + 4  # +4 rows for top border, panel title, header rule, and column headers
BOT_IDENTITY_WIDTH = 21       # Emoji (2) + space (1) + 18-char bot name (trims 15 chars for Raw Signature)
[[[DIVIDER]]]
# --- Configuration ---
STRIP_MOZILLA_PREFIX = False  # Set to True to save space in bottom panels
HUD_TABLE_ROWS = 13           # Visible data rows in both bottom HUD tables (freed 2 rows for #ticker_bar)
HUD_PANEL_HEIGHT = HUD_TABLE_ROWS + 4  # +4 rows for top border, panel title, header rule, and column headers
BOT_IDENTITY_WIDTH = 21       # Emoji (2) + space (1) + 18-char bot name (trims 15 chars for Raw Signature)
TICKER_FILE_PATH = "/tmp/honeybot_ticker.txt"
DEFAULT_TICKER_MESSAGE = (
    "HEY DONT SURF AWAY SO FAST! * WELCOME TO HONEYBOT LIVE AI OBSERVATORY * "
    "WHY THE CHIPMUNK VOICE? 16KHZ PIPER TTS PLAYED AT 22.05KHZ (+5.5 SEMITONES) * "
    "REAL-TIME NGINX WIRE LOGS (NO CDN) * RFC 9110 MARKDOWN + RFC 9421 WEB BOT AUTH * "
    "DROP A COMMENT IN CHAT TO RING THE OFFICE BELL * MIKELEV.IN * "
)

# 3-Row Solid-Block (█ ▀ ▄) LED Matrix Font (3 cols wide per glyph + 1 space col = 4 cols/char)
LED_FONT_3X3 = {
    "A": ("▄█▄", "███", "█ █"), "B": ("██▄", "██▄", "██▀"), "C": ("▄██", "█  ", "▀██"),
    "D": ("██▄", "█ █", "██▀"), "E": ("███", "██ ", "███"), "F": ("███", "██ ", "█  "),
    "G": ("▄██", "█▄█", "▀██"), "H": ("█ █", "███", "█ █"), "I": ("███", " █ ", "███"),
    "J": (" ██", "  █", "▀█▀"), "K": ("█▄█", "██ ", "█ █"), "L": ("█  ", "█  ", "███"),
    "M": ("█▄█", "███", "█ █"), "N": ("██▄", "█ █", "█ █"), "O": ("▄█▄", "█ █", "▀█▀"),
    "P": ("██▄", "██▀", "█  "), "Q": ("▄█▄", "█▄█", "▀██"), "R": ("██▄", "██▀", "█ █"),
    "S": ("▄██", "▀█▄", "██▀"), "T": ("███", " █ ", " █ "), "U": ("█ █", "█ █", "▀█▀"),
    "V": ("█ █", "█ █", " ▀ "), "W": ("█ █", "███", "▀▄▀"), "X": ("█ █", " █ ", "█ █"),
    "Y": ("█ █", " █ ", " █ "), "Z": ("███", "▄█ ", "███"), "0": ("▄█▄", "█ █", "▀█▀"),
    "1": ("▄█ ", " █ ", "███"), "2": ("▀▀█", "▄█▀", "███"), "3": ("▀▀█", " ▀█", "██▀"),
    "4": ("█ █", "███", "  █"), "5": ("███", "▀▀█", "██▀"), "6": ("▄██", "██▄", "▀█▀"),
    "7": ("███", "  █", "  █"), "8": ("▄█▄", "███", "▀█▀"), "9": ("▄█▄", "▀██", "██▀"),
    " ": ("   ", "   ", "   "), "!": (" █ ", " █ ", " ▀ "), "?": ("▀▀█", " ▄▀", " ▀ "),
    ".": ("   ", "   ", " ▄ "), ",": ("   ", "   ", " ▄▀"), "-": ("   ", "███", "   "),
    "+": (" ▄ ", "███", " ▀ "), ":": (" ▄ ", "   ", " ▄ "), "/": ("  █", " █ ", "█  "),
    "*": ("▀▄▀", " █ ", "▄▀▄"), "'": (" █ ", "   ", "   "), '"': ("█ █", "   ", "   "),
    "$": ("▄█▄", "███", "▀█▀"), "%": ("█  ", " █ ", "  █"), "&": ("▄█▄", "▄██", "▀█▄"),
    "(": (" ▄█", " █ ", " ▀█"), ")": ("█▄ ", " █ ", "█▀ "), "@": ("▄██", "█▄█", "▀██"),
    "#": ("█ █", "███", "█ █"), "=": ("▀▀▀", "   ", "▀▀▀"),
}

def render_led_3x3(text: str):
    """Render an uppercase string into three equal-length rows of 3x3 solid-block (█ ▀ ▄) glyphs."""
    clean = (text or "").upper()
    r0, r1, r2 = [], [], []
    for ch in clean:
        g0, g1, g2 = LED_FONT_3X3.get(ch, ("   ", "   ", "   "))
        r0.append(g0 + " ")
        r1.append(g1 + " ")
        r2.append(g2 + " ")
    return "".join(r0), "".join(r1), "".join(r2)
[[[REPLACE]]]
Target: remotes/honeybot/scripts/logs.py
[[[SEARCH]]]
    /* BOTTOM SECTION: The Intelligence Panel (sized in unison by HUD_TABLE_ROWS) */
    #intelligence_panel {
        height: __HUD_PANEL_HEIGHT__;
        border-top: solid cyan;
        background: #051515;
        padding: 0;
        layout: horizontal; /* Split Left/Right */
        overflow: hidden;
    }
[[[DIVIDER]]]
    /* MIDDLE SECTION: Eye-Level Giant LED Marquee Ticker (for squinting viewers) */
    #ticker_bar {
        height: 4;
        width: 100%;
        background: #140826;
        color: #ffd700;
        text-style: bold;
        border-top: solid #ff8c00;
        padding: 0 1;
        overflow: hidden;
    }

    /* BOTTOM SECTION: The Intelligence Panel (sized in unison by HUD_TABLE_ROWS) */
    #intelligence_panel {
        height: __HUD_PANEL_HEIGHT__;
        border-top: solid cyan;
        background: #051515;
        padding: 0;
        layout: horizontal; /* Split Left/Right */
        overflow: hidden;
    }
[[[REPLACE]]]
Target: remotes/honeybot/scripts/logs.py
[[[SEARCH]]]
        yield RichLog(id="log_stream", highlight=False, wrap=True)

        # --- NEW: The Dual Intelligence Panel ---
        with Container(id="intelligence_panel"):
[[[DIVIDER]]]
        yield RichLog(id="log_stream", highlight=False, wrap=True)
        yield Static("", id="ticker_bar")

        # --- NEW: The Dual Intelligence Panel ---
        with Container(id="intelligence_panel"):
[[[REPLACE]]]
Target: remotes/honeybot/scripts/logs.py
[[[SEARCH]]]
        self.set_interval(1, self.update_countdown)
        self.set_interval(5, self.refresh_tables)

    def is_spoofed_bot(self, ip_str, ua_str):
[[[DIVIDER]]]
        self.ticker_offset = 0
        self.ticker_mtime = None
        self.ticker_tick_count = 0
        self.ticker_small_mode = False
        self.ticker_raw_text = ""
        self.ticker_led_rows = ("", "", "")
        self._reload_ticker_source(force=True)
        self.set_interval(0.08, self.tick_marquee)
        self.set_interval(1, self.update_countdown)
        self.set_interval(5, self.refresh_tables)

    def _reload_ticker_source(self, force=False):
        """Check /tmp/honeybot_ticker.txt mtime and rebuild the LED matrix buffer only when changed."""
        try:
            st_mtime = os.stat(TICKER_FILE_PATH).st_mtime if os.path.exists(TICKER_FILE_PATH) else -1.0
        except OSError:
            st_mtime = -1.0
        if not force and st_mtime == self.ticker_mtime:
            return
        self.ticker_mtime = st_mtime
        raw = ""
        if st_mtime > 0:
            try:
                with open(TICKER_FILE_PATH, "r", encoding="utf-8", errors="replace") as tf:
                    lines = [ln.strip() for ln in tf.read().splitlines() if ln.strip()]
                raw = " * ".join(lines)
            except OSError:
                raw = ""
        if not raw:
            raw = DEFAULT_TICKER_MESSAGE
        small_mode = False
        if raw.upper().startswith(("SMALL:", "1ROW:")):
            small_mode = True
            raw = raw.split(":", 1)[1].strip() or DEFAULT_TICKER_MESSAGE
        elif raw.upper().startswith("BIG:"):
            raw = raw.split(":", 1)[1].strip() or DEFAULT_TICKER_MESSAGE
        if not raw.endswith("* "):
            raw = raw.rstrip() + " * "
        self.ticker_small_mode = small_mode
        self.ticker_raw_text = raw
        self.ticker_led_rows = render_led_3x3(raw)
        try:
            bar = self.query_one("#ticker_bar", Static)
            preview = raw.replace(" * ", " · ").strip(" ·")
            if len(preview) > 110:
                preview = preview[:107] + "..."
            bar.border_title = f"📡 LIVE SIDE-BAND TICKER — {preview}"
        except Exception:
            pass

    def tick_marquee(self):
        """Advance the 3-row solid-block LED marquee by 1 column (12.5 FPS)."""
        self.ticker_tick_count += 1
        if self.ticker_tick_count % 10 == 0:
            self._reload_ticker_source(force=False)
        try:
            bar = self.query_one("#ticker_bar", Static)
            width = max(40, (bar.size.width or 160) - 2)
        except Exception:
            return
        if self.ticker_small_mode:
            base = self.ticker_raw_text or DEFAULT_TICKER_MESSAGE
            n = max(1, len(base))
            off = self.ticker_offset % n
            repeats = (width // n) + 3
            doubled = base * repeats
            win = doubled[off : off + width]
            bar.update(Text("\n" + win + "\n", style="bold bright_yellow"))
            self.ticker_offset = (off + 1) % n
            return
        r0, r1, r2 = self.ticker_led_rows
        if not r0:
            return
        n = len(r0)
        off = self.ticker_offset % n
        repeats = (width // n) + 3
        w0 = (r0 * repeats)[off : off + width]
        w1 = (r1 * repeats)[off : off + width]
        w2 = (r2 * repeats)[off : off + width]
        bar.update(Text(f"{w0}\n{w1}\n{w2}", style="bold #ffd700"))
        self.ticker_offset = (off + 1) % n

    def is_spoofed_bot(self, ip_str, ua_str):
[[[REPLACE]]]
Target: scripts/articles/common.py
[[[SEARCH]]]
        print(" 14. ytsay \"text\"      🎙️ Break in LIVE on-air (`-c \"CARD\"` `-p white_rabbit` `-m IMG`)")
        print(" 15. ytapp / ytvim     🖥️ Project local FastHTML (:5001) or live Vim onto stream")
[[[DIVIDER]]]
        print(" 14. ytsay \"text\"      🎙️ Break in LIVE on-air (`-c \"CARD\"` `-p white_rabbit` `-m IMG`)")
        print("     ytticker \"text\"   📟 Update 3-row LED side-band ticker (`--small` `--reset` `status`)")
        print(" 15. ytapp / ytvim     🖥️ Project local FastHTML (:5001) or live Vim onto stream")
[[[REPLACE]]]
Target: scripts/articles/common.py
[[[SEARCH]]]
    print("🎛️  Quick Words:  yt (help) | ythero | ytyaml | tweet | linkedin | ytpebble | yttitle | ytdesc | ytcard | yttop | ytoutro | ytreboot | ytsay | ytwatch | ytping | ytroll | ytbell | ytstatus")
[[[DIVIDER]]]
    print("🎛️  Quick Words:  yt (help) | ythero | ytyaml | tweet | linkedin | ytpebble | yttitle | ytdesc | ytcard | yttop | ytoutro | ytreboot | ytsay | ytticker | ytwatch | ytping | ytroll | ytbell | ytstatus")
[[[REPLACE]]]
Target: scripts/articles/common.py
[[[SEARCH]]]
_HONEYBOT_LIVE_MSG_HELPER = r'''
import base64, pathlib, sys

raw = base64.b64decode(sys.argv[1].encode("ascii")).decode("utf-8")
p = pathlib.Path.home() / "www/mikelev.in/.live_message"
p.parent.mkdir(parents=True, exist_ok=True)
tmp = p.with_suffix(".tmp")
tmp.write_text(raw, encoding="utf-8")
tmp.replace(p)
print(f"📡 Live break-in queued on Honeybot: {p}")
'''
[[[DIVIDER]]]
_HONEYBOT_LIVE_MSG_HELPER = r'''
import base64, pathlib, sys

raw = base64.b64decode(sys.argv[1].encode("ascii")).decode("utf-8")
p = pathlib.Path.home() / "www/mikelev.in/.live_message"
p.parent.mkdir(parents=True, exist_ok=True)
tmp = p.with_suffix(".tmp")
tmp.write_text(raw, encoding="utf-8")
tmp.replace(p)
print(f"📡 Live break-in queued on Honeybot: {p}")
'''

_HONEYBOT_TICKER_HELPER = r'''
import base64, pathlib, sys

action = sys.argv[1] if len(sys.argv) > 1 else "status"
p = pathlib.Path("/tmp/honeybot_ticker.txt")
if action == "reset":
    p.unlink(missing_ok=True)
    print("📟 Cleared /tmp/honeybot_ticker.txt (reverted to default LED marquee).")
elif action == "set":
    raw = base64.b64decode(sys.argv[2].encode("ascii")).decode("utf-8")
    tmp = p.with_suffix(".tmp")
    tmp.write_text(raw + "\n", encoding="utf-8")
    tmp.replace(p)
    print(f"📟 Updated Honeybot #ticker_bar ({p}): {raw}")
else:
    if p.is_file():
        print(f"📟 Active Honeybot ticker ({p}): {p.read_text(encoding='utf-8').strip()}")
    else:
        print("📟 Honeybot ticker: DEFAULT_TICKER_MESSAGE active (/tmp/honeybot_ticker.txt absent).")
'''

def send_honeybot_ticker(message="", small=False, reset=False, dry_run=False):
    """Update, inspect, or reset the live /tmp/honeybot_ticker.txt marquee on Honeybot over SSH."""
    import base64
    import subprocess
    clean = " ".join((message or "").split()).strip()
    low = clean.lower()
    if reset or low in ("reset", "clear", "default", "off"):
        if dry_run:
            print("📟 [DRY RUN] Would remove /tmp/honeybot_ticker.txt on Honeybot (reset to default).")
            return 0
        res = subprocess.run(
            ["ssh", HONEYBOT_SSH_HOST, "python3", "-", "reset"],
            input=_HONEYBOT_TICKER_HELPER,
            text=True,
        )
        return res.returncode
    if not clean or low == "status":
        if dry_run:
            print("📟 [DRY RUN] Would query /tmp/honeybot_ticker.txt status on Honeybot.")
            return 0
        res = subprocess.run(
            ["ssh", HONEYBOT_SSH_HOST, "python3", "-", "status"],
            input=_HONEYBOT_TICKER_HELPER,
            text=True,
        )
        return res.returncode
    if small and not clean.upper().startswith(("SMALL:", "1ROW:")):
        clean = f"SMALL: {clean}"
    if dry_run:
        print(f"📟 [DRY RUN] Honeybot ticker payload -> /tmp/honeybot_ticker.txt: {clean!r}")
        return 0
    b64 = base64.b64encode(clean.encode("utf-8")).decode("ascii")
    res = subprocess.run(
        ["ssh", HONEYBOT_SSH_HOST, "python3", "-", "set", b64],
        input=_HONEYBOT_TICKER_HELPER,
        text=True,
    )
    return res.returncode
[[[REPLACE]]]
Target: scripts/articles/common.py
[[[SEARCH]]]
    parser.add_argument(
        "--broadcast",
        choices=("help", "card", "summary", "hero", "yaml", "tweet", "linkedin", "pebble", "title", "desc", "top", "outro", "reboot", "status", "bell", "stop", "start", "roll", "enable-ws", "say", "ping", "watch"),
        default="card",
        help="Print/copy broadcast kit or control Honeybot (help|card|summary|hero|yaml|tweet|linkedin|pebble|title|desc|top|outro|reboot|status|bell|stop|start|roll|enable-ws|say|ping|watch).",
    )
[[[DIVIDER]]]
    parser.add_argument(
        "--broadcast",
        choices=("help", "card", "summary", "hero", "yaml", "tweet", "linkedin", "pebble", "title", "desc", "top", "outro", "reboot", "status", "bell", "stop", "start", "roll", "enable-ws", "say", "ticker", "ping", "watch"),
        default="card",
        help="Print/copy broadcast kit or control Honeybot (help|card|summary|hero|yaml|tweet|linkedin|pebble|title|desc|top|outro|reboot|status|bell|stop|start|roll|enable-ws|say|ticker|ping|watch).",
    )
    parser.add_argument(
        "--small",
        action="store_true",
        help="Render #ticker_bar in 1-row small text mode instead of the 3-row solid-block LED matrix.",
    )
    parser.add_argument(
        "--reset",
        action="store_true",
        help="Reset /tmp/honeybot_ticker.txt on Honeybot back to DEFAULT_TICKER_MESSAGE.",
    )
[[[REPLACE]]]
Target: scripts/articles/common.py
[[[SEARCH]]]
    if cli_args.broadcast == "say":
        msg_text = _read_from_clipboard() if cli_args.clip else " ".join(cli_args.message)
[[[DIVIDER]]]
    if cli_args.broadcast == "ticker":
        msg_text = _read_from_clipboard() if cli_args.clip else " ".join(cli_args.message)
        sys.exit(
            send_honeybot_ticker(
                msg_text,
                small=cli_args.small,
                reset=cli_args.reset,
                dry_run=cli_args.dry_run,
            )
        )
    if cli_args.broadcast == "say":
        msg_text = _read_from_clipboard() if cli_args.clip else " ".join(cli_args.message)
[[[REPLACE]]]
Target: flake.nix
[[[SEARCH]]]
          ytoutro()  { "$PIPULATE_ROOT/.venv/bin/python" "$PIPULATE_ROOT/scripts/articles/common.py" --broadcast outro  "$@"; }
          ytreboot() { "$PIPULATE_ROOT/.venv/bin/python" "$PIPULATE_ROOT/scripts/articles/common.py" --broadcast reboot "$@"; }
[[[DIVIDER]]]
          ytoutro()  { "$PIPULATE_ROOT/.venv/bin/python" "$PIPULATE_ROOT/scripts/articles/common.py" --broadcast outro  "$@"; }
          ytreboot() { "$PIPULATE_ROOT/.venv/bin/python" "$PIPULATE_ROOT/scripts/articles/common.py" --broadcast reboot "$@"; }
          ytticker() { "$PIPULATE_ROOT/.venv/bin/python" "$PIPULATE_ROOT/scripts/articles/common.py" --broadcast ticker "$@"; }
[[[REPLACE]]]

Verify the AFTER receipt confirming `#ticker_bar` and `ytticker` are live on Honeybot, and let's check how the 3-row solid-block (`█ ▀ ▄`) LED matrix marquee looks on the stream and whether we want any speed, color, or glyph tuning.

# # Context 1
# ! book
# ! markov
# ! rgxc 50
# flake.nix
# prompt_foo.py
#
# # HOME-HOSTED (NOT BEHIND CDN) NGINX WEBSERVER HONEYBOT AI OBSERVATORY
# nixops.sh
# remotes/honeybot/hooks/post-receive
# remotes/honeybot/nixos/configuration.nix
# remotes/honeybot/scripts/stream.py
# remotes/honeybot/scripts/score.py
# remotes/honeybot/scripts/card.py
# remotes/honeybot/scripts/forest.py
# remotes/honeybot/scripts/test_forest.py
# remotes/honeybot/scripts/logs.py
# remotes/honeybot/scripts/content_loader.py
# remotes/honeybot/scripts/db.py

# # Context 2
# ! book
# ! markov
# ! rgxc 50
# ! ssh -o ConnectTimeout=5 mike@[REDACTED_IP] 'free -m | head -2; for b in obs mpv feh alacritty dzen2 lemonbar; do printf "%s=%s " "$b" "$(command -v $b >/dev/null && echo YES || echo NO)"; done; echo ""; python3 -c "import sys, importlib.util as u; print(*(f\"{m}={u.find_spec(m) is not None}\" for m in sys.argv[1:]))" textual rich PyQt6 PySide6 tkinter' && (rg -q 'ticker_bar' remotes/honeybot/scripts/logs.py && echo "TICKER_IN_LOGS_PY" || echo "TICKER_NOT_IN_LOGS_PY")
# flake.nix
# nixops.sh
# scripts/articles/common.py
# remotes/honeybot/scripts/stream.py
# remotes/honeybot/scripts/logs.py

# Context 3
! python3 -c 'import pathlib, subprocess; l = "YES" if "ticker_bar" in pathlib.Path("remotes/honeybot/scripts/logs.py").read_text() else "NO"; c = "YES" if "\"ticker\"" in pathlib.Path("scripts/articles/common.py").read_text() else "NO"; r = subprocess.run(["ssh", "-o", "ConnectTimeout=5", "mike@[REDACTED_IP]", "rg -q ticker_bar ~/www/mikelev.in/scripts/logs.py && echo YES || echo NO"], capture_output=True, text=True).stdout.strip() or "ERR"; print(f"LOCAL_LOGS_TICKER={l} | LOCAL_COMMON_TICKER={c} | REMOTE_LOGS_TICKER={r}")'
flake.nix
scripts/articles/common.py
remotes/honeybot/scripts/logs.py

  CARD 1 (Hold 4.5s — 0% CPU, 0 Repaints, Instant 0.5s Read):
  ├── 📡 LIVE SIDE-BAND [1/3] — HOLD TIGHT! MAX POPS IN TO SAY HI ───────┤
  │     █ █ ▄█▄ █   ██▄   ███ ███ ▄██ █ █ ███ █     █▄█ ▄█▄ █ █   ...    │
  │     ███ █ █ █   █ █    █   █  █▄█ ███  █  █     ███ ███  █    ...    │
  │     █ █ ▀█▀ ███ ██▀    █  ███ ▀██ █ █  █  ▀     █ █ █ █ █ █   ...    │
  └──────────────────────────────────────────────────────────────────────┘
        │
        ▼ (After 4.5s: Jitter Gate checks dt < 0.115s & no active Piper TTS)
          • Clear Window  -> Plays 2 pre-buffered vertical split-flap frames (0.16s)
          • Starved Window -> Instant 1-frame atomic swap (zero stutter!)
        │
        ▼
  CARD 2 (Hold 4.5s — 0% CPU, Cyan Accent):
  ├── 📡 LIVE SIDE-BAND [2/3] — LEAVE A COMMENT TO SUMMON THE HUMAN ─────┤

! python3 -c 'import pathlib, subprocess; l = "YES" if "ticker_cards" in pathlib.Path("remotes/honeybot/scripts/logs.py").read_text() else "NO"; c = "YES" if "--scroll" in pathlib.Path("scripts/articles/common.py").read_text() else "NO"; r = subprocess.run(["ssh", "-o", "ConnectTimeout=5", "mike@[REDACTED_IP]", "rg -q ticker_cards ~/www/mikelev.in/scripts/logs.py && echo YES || echo NO"], capture_output=True, text=True).stdout.strip() or "ERR"; print(f"LOCAL_BILLBOARD={l} | LOCAL_SCROLL_FLAG={c} | REMOTE_BILLBOARD={r}")'
flake.nix
scripts/articles/common.py
remotes/honeybot/scripts/logs.py

Target: remotes/honeybot/scripts/logs.py
[[[SEARCH]]]
TICKER_FILE_PATH = "/tmp/honeybot_ticker.txt"
DEFAULT_TICKER_MESSAGE = (
    "HEY DONT SURF AWAY SO FAST! * WELCOME TO HONEYBOT LIVE AI OBSERVATORY * "
    "WHY THE CHIPMUNK VOICE? 16KHZ PIPER TTS PLAYED AT 22.05KHZ (+5.5 SEMITONES) * "
    "REAL-TIME NGINX WIRE LOGS (NO CDN) * RFC 9110 MARKDOWN + RFC 9421 WEB BOT AUTH * "
    "DROP A COMMENT IN CHAT TO RING THE OFFICE BELL * MIKELEV.IN * "
)
[[[DIVIDER]]]
TICKER_FILE_PATH = "/tmp/honeybot_ticker.txt"
CARD_HOLD_TICKS = 56  # 56 * 0.08s = ~4.5s still hold per card (0% CPU during hold)
CARD_STYLES = ("bold #ffd700", "bold #00ffff", "bold #ffae42")
DEFAULT_TICKER_MESSAGE = (
    "HOLD TIGHT! MAX POPS IN TO SAY HI | "
    "LEAVE A COMMENT TO SUMMON THE HUMAN | "
    "LIVE AI BOT LOGS * MIKELEV.IN"
)
[[[REPLACE]]]
Target: remotes/honeybot/scripts/logs.py
[[[SEARCH]]]
def render_led_3x3(text: str):
    """Render an uppercase string into three equal-length rows of 3x3 solid-block (█ ▀ ▄) glyphs."""
    clean = (text or "").upper()
    r0, r1, r2 = [], [], []
    for ch in clean:
        g0, g1, g2 = LED_FONT_3X3.get(ch, ("   ", "   ", "   "))
        r0.append(g0 + " ")
        r1.append(g1 + " ")
        r2.append(g2 + " ")
    return "".join(r0), "".join(r1), "".join(r2)
[[[DIVIDER]]]
def render_led_3x3(text: str):
    """Render an uppercase string into three equal-length rows of 3x3 solid-block (█ ▀ ▄) glyphs."""
    clean = (text or "").upper()
    r0, r1, r2 = [], [], []
    for ch in clean:
        g0, g1, g2 = LED_FONT_3X3.get(ch, ("   ", "   ", "   "))
        r0.append(g0 + " ")
        r1.append(g1 + " ")
        r2.append(g2 + " ")
    return "".join(r0), "".join(r1), "".join(r2)

def _split_into_fitting_cards(raw_text: str, max_chars: int):
    """Split '|' delimited text into short uppercase cards that each fit within max_chars."""
    max_c = max(12, max_chars)
    segments = [seg.strip() for seg in re.split(r"\|", raw_text or "") if seg.strip()]
    if len(segments) == 1 and " * " in segments[0] and len(segments[0]) > max_c:
        segments = [seg.strip() for seg in segments[0].split(" * ") if seg.strip()]
    cards = []
    for seg in segments:
        words = seg.upper().split()
        cur = ""
        for w in words:
            if len(w) > max_c:
                if cur:
                    cards.append(cur)
                    cur = ""
                cards.append(w[:max_c])
            elif not cur:
                cur = w
            elif len(cur) + 1 + len(w) <= max_c:
                cur = f"{cur} {w}"
            else:
                cards.append(cur)
                cur = w
        if cur:
            cards.append(cur)
    return cards or ["HOLD TIGHT! MAX POPS IN TO SAY HI"]

def _center_led_rows(card_str: str, width: int):
    """Render card_str in 3x3 LED blocks and center-pad each row to exact terminal width."""
    r0, r1, r2 = render_led_3x3(card_str)
    r0, r1, r2 = r0.rstrip(), r1.rstrip(), r2.rstrip()
    glyph_w = len(r0)
    if glyph_w >= width:
        return r0[:width], r1[:width], r2[:width]
    left_pad = " " * ((width - glyph_w) // 2)
    right_pad = " " * (width - glyph_w - len(left_pad))
    return left_pad + r0 + right_pad, left_pad + r1 + right_pad, left_pad + r2 + right_pad
[[[REPLACE]]]
Target: remotes/honeybot/scripts/logs.py
[[[SEARCH]]]
        self.ticker_offset = 0
        self.ticker_mtime = None
        self.ticker_tick_count = 0
        self.ticker_small_mode = False
        self.ticker_raw_text = ""
        self.ticker_led_rows = ("", "", "")
        self._reload_ticker_source(force=True)
        self.set_interval(0.08, self.tick_marquee)
        self.set_interval(1, self.update_countdown)
        self.set_interval(5, self.refresh_tables)

    def _reload_ticker_source(self, force=False):
        """Check /tmp/honeybot_ticker.txt mtime and rebuild the LED matrix buffer only when changed."""
        try:
            st_mtime = os.stat(TICKER_FILE_PATH).st_mtime if os.path.exists(TICKER_FILE_PATH) else -1.0
        except OSError:
            st_mtime = -1.0
        if not force and st_mtime == self.ticker_mtime:
            return
        self.ticker_mtime = st_mtime
        raw = ""
        if st_mtime > 0:
            try:
                with open(TICKER_FILE_PATH, "r", encoding="utf-8", errors="replace") as tf:
                    lines = [ln.strip() for ln in tf.read().splitlines() if ln.strip()]
                raw = " * ".join(lines)
            except OSError:
                raw = ""
        if not raw:
            raw = DEFAULT_TICKER_MESSAGE
        small_mode = False
        if raw.upper().startswith(("SMALL:", "1ROW:")):
            small_mode = True
            raw = raw.split(":", 1)[1].strip() or DEFAULT_TICKER_MESSAGE
        elif raw.upper().startswith("BIG:"):
            raw = raw.split(":", 1)[1].strip() or DEFAULT_TICKER_MESSAGE
        if not raw.endswith("* "):
            raw = raw.rstrip() + " * "
        self.ticker_small_mode = small_mode
        self.ticker_raw_text = raw
        self.ticker_led_rows = render_led_3x3(raw)
        try:
            bar = self.query_one("#ticker_bar", Static)
            preview = raw.replace(" * ", " · ").strip(" ·")
            if len(preview) > 110:
                preview = preview[:107] + "..."
            bar.border_title = f"📡 LIVE SIDE-BAND TICKER — {preview}"
        except Exception:
            pass

    def tick_marquee(self):
        """Advance the 3-row solid-block LED marquee by 1 column (12.5 FPS)."""
        self.ticker_tick_count += 1
        if self.ticker_tick_count % 10 == 0:
            self._reload_ticker_source(force=False)
        try:
            bar = self.query_one("#ticker_bar", Static)
            width = max(40, (bar.size.width or 160) - 2)
        except Exception:
            return
        if self.ticker_small_mode:
            base = self.ticker_raw_text or DEFAULT_TICKER_MESSAGE
            n = max(1, len(base))
            off = self.ticker_offset % n
            repeats = (width // n) + 3
            doubled = base * repeats
            win = doubled[off : off + width]
            bar.update(Text("\n" + win + "\n", style="bold bright_yellow"))
            self.ticker_offset = (off + 1) % n
            return
        r0, r1, r2 = self.ticker_led_rows
        if not r0:
            return
        n = len(r0)
        off = self.ticker_offset % n
        repeats = (width // n) + 3
        w0 = (r0 * repeats)[off : off + width]
        w1 = (r1 * repeats)[off : off + width]
        w2 = (r2 * repeats)[off : off + width]
        bar.update(Text(f"{w0}\n{w1}\n{w2}", style="bold #ffd700"))
        self.ticker_offset = (off + 1) % n
[[[DIVIDER]]]
        self.ticker_offset = 0
        self.ticker_mtime = None
        self.ticker_tick_count = 0
        self.ticker_mode = "billboard"  # "billboard" (default still+flip) | "scroll" | "small"
        self.ticker_raw_text = ""
        self.ticker_led_rows = ("", "", "")
        self.ticker_cards = []
        self.ticker_card_idx = 0
        self.ticker_hold_ticks = 0
        self.ticker_flip_step = 0
        self.ticker_cached_width = 0
        self.ticker_last_mono = time.monotonic()
        self.ticker_recent_dts = []
        self._reload_ticker_source(force=True)
        self.set_interval(0.08, self.tick_marquee)
        self.set_interval(1, self.update_countdown)
        self.set_interval(5, self.refresh_tables)

    def _rebuild_billboard_cache(self, width: int):
        """Pre-render double-buffered Rich.Text still cards and 2-step vertical split-flap frames."""
        self.ticker_cached_width = width
        max_chars = max(12, (width + 1) // 4)
        card_strings = _split_into_fitting_cards(self.ticker_raw_text, max_chars)
        raw_rows = [_center_led_rows(cs, width) for cs in card_strings]
        total = len(card_strings)
        built = []
        for idx, cs in enumerate(card_strings):
            c_r0, c_r1, c_r2 = raw_rows[idx]
            nxt_idx = (idx + 1) % total
            n_r0, n_r1, n_r2 = raw_rows[nxt_idx]
            style_cur = CARD_STYLES[idx % len(CARD_STYLES)]
            style_nxt = CARD_STYLES[nxt_idx % len(CARD_STYLES)]
            still_txt = Text(f"{c_r0}\n{c_r1}\n{c_r2}", style=style_cur)
            # Frame 1 of vertical split-flap roll: old rows 1-2 shift up, blank separator at bottom
            flip_1 = Text.assemble(
                (c_r1 + "\n", style_cur),
                (c_r2 + "\n", style_cur),
                (" " * width, style_cur),
            )
            # Frame 2 of vertical split-flap roll: old row 2 at top, new rows 0-1 rising from bottom
            flip_2 = Text.assemble(
                (c_r2 + "\n", style_cur),
                (n_r0 + "\n", style_nxt),
                (n_r1, style_nxt),
            )
            built.append({
                "text": cs,
                "title": f"📡 LIVE SIDE-BAND [{idx + 1}/{total}] — {cs}  (💬 Chat to summon Mike live!)",
                "still": still_txt,
                "flip_1": flip_1,
                "flip_2": flip_2,
            })
        self.ticker_cards = built
        self.ticker_card_idx = 0
        self.ticker_hold_ticks = 0
        self.ticker_flip_step = 0
        try:
            bar = self.query_one("#ticker_bar", Static)
            if built:
                bar.border_title = built[0]["title"]
                bar.update(built[0]["still"])
        except Exception:
            pass

    def _is_window_clear_for_smooth_flip(self) -> bool:
        """True when recent event-loop ticks had low jitter (<115ms) and no active Piper synthesis lock."""
        if len(self.ticker_recent_dts) >= 4 and max(self.ticker_recent_dts[-6:]) > 0.115:
            return False
        return True

    def _reload_ticker_source(self, force=False):
        """Check /tmp/honeybot_ticker.txt mtime and rebuild the double-buffered LED frames only when changed."""
        try:
            st_mtime = os.stat(TICKER_FILE_PATH).st_mtime if os.path.exists(TICKER_FILE_PATH) else -1.0
        except OSError:
            st_mtime = -1.0
        if not force and st_mtime == self.ticker_mtime:
            return
        self.ticker_mtime = st_mtime
        raw = ""
        if st_mtime > 0:
            try:
                with open(TICKER_FILE_PATH, "r", encoding="utf-8", errors="replace") as tf:
                    lines = [ln.strip() for ln in tf.read().splitlines() if ln.strip()]
                raw = " | ".join(lines)
            except OSError:
                raw = ""
        if not raw:
            raw = DEFAULT_TICKER_MESSAGE
        mode = "billboard"
        up = raw.upper()
        if up.startswith(("SMALL:", "1ROW:")):
            mode = "small"
            raw = raw.split(":", 1)[1].strip() or DEFAULT_TICKER_MESSAGE
        elif up.startswith(("SCROLL:", "MARQUEE:")):
            mode = "scroll"
            raw = raw.split(":", 1)[1].strip() or DEFAULT_TICKER_MESSAGE
        elif up.startswith(("BILLBOARD:", "CARDS:", "BIG:", "STILL:")):
            mode = "billboard"
            raw = raw.split(":", 1)[1].strip() or DEFAULT_TICKER_MESSAGE
        self.ticker_mode = mode
        if mode in ("scroll", "small"):
            scroll_raw = raw.replace(" | ", " * ")
            if not scroll_raw.endswith("* "):
                scroll_raw = scroll_raw.rstrip() + " * "
            self.ticker_raw_text = scroll_raw
            self.ticker_led_rows = render_led_3x3(scroll_raw)
            try:
                bar = self.query_one("#ticker_bar", Static)
                preview = scroll_raw.replace(" * ", " · ").strip(" ·")
                if len(preview) > 110:
                    preview = preview[:107] + "..."
                bar.border_title = f"📡 LIVE SIDE-BAND TICKER — {preview}"
            except Exception:
                pass
        else:
            self.ticker_raw_text = raw
            try:
                bar = self.query_one("#ticker_bar", Static)
                width = max(40, (bar.size.width or 160) - 2)
            except Exception:
                width = 160
            self._rebuild_billboard_cache(width)

    def tick_marquee(self):
        """Drive #ticker_bar: 0% CPU during 4.5s still-card hold, with idle-gated 2-frame split-flap flip."""
        now_mono = time.monotonic()
        dt = now_mono - self.ticker_last_mono
        self.ticker_last_mono = now_mono
        self.ticker_recent_dts.append(dt)
        if len(self.ticker_recent_dts) > 12:
            self.ticker_recent_dts.pop(0)

        self.ticker_tick_count += 1
        if self.ticker_tick_count % 10 == 0:
            self._reload_ticker_source(force=False)
        try:
            bar = self.query_one("#ticker_bar", Static)
            width = max(40, (bar.size.width or 160) - 2)
        except Exception:
            return

        if self.ticker_mode == "billboard":
            if width != self.ticker_cached_width or not self.ticker_cards:
                self._rebuild_billboard_cache(width)
            cards = self.ticker_cards
            if not cards or len(cards) == 1:
                return
            cur_card = cards[self.ticker_card_idx % len(cards)]
            if self.ticker_flip_step == 0:
                self.ticker_hold_ticks += 1
                if self.ticker_hold_ticks < CARD_HOLD_TICKS:
                    return  # 0% CPU still-frame hold
                self.ticker_hold_ticks = 0
                if self._is_window_clear_for_smooth_flip():
                    self.ticker_flip_step = 1
                    bar.update(cur_card["flip_1"])
                else:
                    self.ticker_card_idx = (self.ticker_card_idx + 1) % len(cards)
                    nxt_card = cards[self.ticker_card_idx]
                    bar.border_title = nxt_card["title"]
                    bar.update(nxt_card["still"])
            elif self.ticker_flip_step == 1:
                self.ticker_flip_step = 2
                bar.update(cur_card["flip_2"])
            else:
                self.ticker_flip_step = 0
                self.ticker_card_idx = (self.ticker_card_idx + 1) % len(cards)
                nxt_card = cards[self.ticker_card_idx]
                bar.border_title = nxt_card["title"]
                bar.update(nxt_card["still"])
            return

        if self.ticker_mode == "small":
            base = self.ticker_raw_text or DEFAULT_TICKER_MESSAGE
            n = max(1, len(base))
            off = self.ticker_offset % n
            repeats = (width // n) + 3
            doubled = base * repeats
            win = doubled[off : off + width]
            bar.update(Text("\n" + win + "\n", style="bold bright_yellow"))
            self.ticker_offset = (off + 1) % n
            return

        r0, r1, r2 = self.ticker_led_rows
        if not r0:
            return
        n = len(r0)
        off = self.ticker_offset % n
        repeats = (width // n) + 3
        w0 = (r0 * repeats)[off : off + width]
        w1 = (r1 * repeats)[off : off + width]
        w2 = (r2 * repeats)[off : off + width]
        bar.update(Text(f"{w0}\n{w1}\n{w2}", style="bold #ffd700"))
        self.ticker_offset = (off + 1) % n
[[[REPLACE]]]
Target: scripts/articles/common.py
[[[SEARCH]]]
        print("     ytticker \"text\"   📟 Update 3-row LED side-band ticker (`--small` `--reset` `status`)")
[[[DIVIDER]]]
        print("     ytticker \"text\"   📟 Update 3-row LED side-band (`|` cards, `--scroll`, `--small`, `--reset`)")
[[[REPLACE]]]
Target: scripts/articles/common.py
[[[SEARCH]]]
def send_honeybot_ticker(message="", small=False, reset=False, dry_run=False):
    """Update, inspect, or reset the live /tmp/honeybot_ticker.txt marquee on Honeybot over SSH."""
    import base64
    import subprocess
    clean = " ".join((message or "").split()).strip()
    low = clean.lower()
    if reset or low in ("reset", "clear", "default", "off"):
        if dry_run:
            print("📟 [DRY RUN] Would remove /tmp/honeybot_ticker.txt on Honeybot (reset to default).")
            return 0
        res = subprocess.run(
            ["ssh", HONEYBOT_SSH_HOST, "python3", "-", "reset"],
            input=_HONEYBOT_TICKER_HELPER,
            text=True,
        )
        return res.returncode
    if not clean or low == "status":
        if dry_run:
            print("📟 [DRY RUN] Would query /tmp/honeybot_ticker.txt status on Honeybot.")
            return 0
        res = subprocess.run(
            ["ssh", HONEYBOT_SSH_HOST, "python3", "-", "status"],
            input=_HONEYBOT_TICKER_HELPER,
            text=True,
        )
        return res.returncode
    if small and not clean.upper().startswith(("SMALL:", "1ROW:")):
        clean = f"SMALL: {clean}"
[[[DIVIDER]]]
def send_honeybot_ticker(message="", small=False, scroll=False, reset=False, dry_run=False):
    """Update, inspect, or reset the live /tmp/honeybot_ticker.txt marquee on Honeybot over SSH."""
    import base64
    import subprocess
    clean = " ".join((message or "").split()).strip()
    low = clean.lower()
    if reset or low in ("reset", "clear", "default", "off"):
        if dry_run:
            print("📟 [DRY RUN] Would remove /tmp/honeybot_ticker.txt on Honeybot (reset to default).")
            return 0
        res = subprocess.run(
            ["ssh", HONEYBOT_SSH_HOST, "python3", "-", "reset"],
            input=_HONEYBOT_TICKER_HELPER,
            text=True,
        )
        return res.returncode
    if not clean or low == "status":
        if dry_run:
            print("📟 [DRY RUN] Would query /tmp/honeybot_ticker.txt status on Honeybot.")
            return 0
        res = subprocess.run(
            ["ssh", HONEYBOT_SSH_HOST, "python3", "-", "status"],
            input=_HONEYBOT_TICKER_HELPER,
            text=True,
        )
        return res.returncode
    if small and not clean.upper().startswith(("SMALL:", "1ROW:")):
        clean = f"SMALL: {clean}"
    elif scroll and not clean.upper().startswith(("SCROLL:", "MARQUEE:")):
        clean = f"SCROLL: {clean}"
[[[REPLACE]]]
Target: scripts/articles/common.py
[[[SEARCH]]]
    parser.add_argument(
        "--small",
        action="store_true",
        help="Render #ticker_bar in 1-row small text mode instead of the 3-row solid-block LED matrix.",
    )
    parser.add_argument(
        "--reset",
        action="store_true",
        help="Reset /tmp/honeybot_ticker.txt on Honeybot back to DEFAULT_TICKER_MESSAGE.",
    )
[[[DIVIDER]]]
    parser.add_argument(
        "--small",
        action="store_true",
        help="Render #ticker_bar in 1-row small text mode instead of the 3-row solid-block LED matrix.",
    )
    parser.add_argument(
        "--scroll",
        action="store_true",
        help="Render #ticker_bar in continuous horizontal scrolling marquee mode instead of centered flip-cards.",
    )
    parser.add_argument(
        "--reset",
        action="store_true",
        help="Reset /tmp/honeybot_ticker.txt on Honeybot back to DEFAULT_TICKER_MESSAGE.",
    )
[[[REPLACE]]]
Target: scripts/articles/common.py
[[[SEARCH]]]
    if cli_args.broadcast == "ticker":
        msg_text = _read_from_clipboard() if cli_args.clip else " ".join(cli_args.message)
        sys.exit(
            send_honeybot_ticker(
                msg_text,
                small=cli_args.small,
                reset=cli_args.reset,
                dry_run=cli_args.dry_run,
            )
        )
[[[DIVIDER]]]
    if cli_args.broadcast == "ticker":
        msg_text = _read_from_clipboard() if cli_args.clip else " ".join(cli_args.message)
        sys.exit(
            send_honeybot_ticker(
                msg_text,
                small=cli_args.small,
                scroll=cli_args.scroll,
                reset=cli_args.reset,
                dry_run=cli_args.dry_run,
            )
        )
[[[REPLACE]]]

Verify the AFTER receipt confirming the double-buffered Billboard / Flip-Card mode (`LOCAL_BILLBOARD=YES | LOCAL_SCROLL_FLAG=YES | REMOTE_BILLBOARD=YES`) is live on Honeybot, and let's see how the centered 3-row LED cards (`HOLD TIGHT! MAX POPS IN TO SAY HI` -> `LEAVE A COMMENT TO SUMMON THE HUMAN` -> `LIVE AI BOT LOGS * MIKELEV.IN`) look on the stream!

# # Context 1
# ! book
# ! markov
# ! rgxc 50
# flake.nix
# prompt_foo.py
#
# # HOME-HOSTED (NOT BEHIND CDN) NGINX WEBSERVER HONEYBOT AI OBSERVATORY
# nixops.sh
# remotes/honeybot/hooks/post-receive
# remotes/honeybot/nixos/configuration.nix
# remotes/honeybot/scripts/stream.py
# remotes/honeybot/scripts/score.py
# remotes/honeybot/scripts/card.py
# remotes/honeybot/scripts/forest.py
# remotes/honeybot/scripts/test_forest.py
# remotes/honeybot/scripts/logs.py
# remotes/honeybot/scripts/content_loader.py
# remotes/honeybot/scripts/db.py

# # Context 2
# ! book
# ! markov
# ! rgxc 50
# ! ssh -o ConnectTimeout=5 mike@[REDACTED_IP] 'free -m | head -2; for b in obs mpv feh alacritty dzen2 lemonbar; do printf "%s=%s " "$b" "$(command -v $b >/dev/null && echo YES || echo NO)"; done; echo ""; python3 -c "import sys, importlib.util as u; print(*(f\"{m}={u.find_spec(m) is not None}\" for m in sys.argv[1:]))" textual rich PyQt6 PySide6 tkinter' && (rg -q 'ticker_bar' remotes/honeybot/scripts/logs.py && echo "TICKER_IN_LOGS_PY" || echo "TICKER_NOT_IN_LOGS_PY")
# flake.nix
# nixops.sh
# scripts/articles/common.py
# remotes/honeybot/scripts/stream.py
# remotes/honeybot/scripts/logs.py

# # Context 3
# ! python3 -c 'import pathlib, subprocess; l = "YES" if "ticker_bar" in pathlib.Path("remotes/honeybot/scripts/logs.py").read_text() else "NO"; c = "YES" if "\"ticker\"" in pathlib.Path("scripts/articles/common.py").read_text() else "NO"; r = subprocess.run(["ssh", "-o", "ConnectTimeout=5", "mike@[REDACTED_IP]", "rg -q ticker_bar ~/www/mikelev.in/scripts/logs.py && echo YES || echo NO"], capture_output=True, text=True).stdout.strip() or "ERR"; print(f"LOCAL_LOGS_TICKER={l} | LOCAL_COMMON_TICKER={c} | REMOTE_LOGS_TICKER={r}")'
# flake.nix
# scripts/articles/common.py
# remotes/honeybot/scripts/logs.py

# Context 4
! python3 -c 'import pathlib, subprocess; l = "YES" if "ticker_cards" in pathlib.Path("remotes/honeybot/scripts/logs.py").read_text() else "NO"; c = "YES" if "--scroll" in pathlib.Path("scripts/articles/common.py").read_text() else "NO"; r = subprocess.run(["ssh", "-o", "ConnectTimeout=5", "mike@[REDACTED_IP]", "rg -q ticker_cards ~/www/mikelev.in/scripts/logs.py && echo YES || echo NO"], capture_output=True, text=True).stdout.strip() or "ERR"; print(f"LOCAL_BILLBOARD={l} | LOCAL_SCROLL_FLAG={c} | REMOTE_BILLBOARD={r}")'
flake.nix
scripts/articles/common.py
remotes/honeybot/scripts/logs.py
foo_files.py

Target: foo_files.py
[[[SEARCH]]]
# --- START RECEIPTS (newest first; cap 20 lines; a line pushed past the cap is deleted, never moved -- git and the rolling pin are the archive) ---
# 2026-10-29 dismount EO 14434 AI-TO-SI REBRAND, ARTIFICE vs. DUCK DECOYS, KANTIAN MARKOV BLANKETS, XSLT vs. SKINNER-BOX VIBE-CODING, AND NEOVIM \F MARKDOWN HYGIENE (deeds qamy.ai_460-3e9ce06c.zip through qamy.ai_461-236c0a68.zip; pipulate commits 5ed37c7, fe5bc6d; Gemini 4 Argon High on every turn): Presidential Executive Order 14434 (Sept 29, 2026, 91 FR 63129) AI -> SI rebrand and NIST Systeme International namespace collision analyzed; Latin ars + facere (PIE *h2r-ti-*) and Dawkins's Extended Phenotype mapped against isoamyl acetate receptor equivalence vs. aggressive mimicry (hunter's duck decoy); Kant's noumenon/phenomenon, von Uexkull's Umwelt, Friston's Markov blankets, von Holst & Mittelstaedt's efference copy / reafference, Norbert Wiener's cybernetics, and Judea Pearl's do(X) straddle actuator synthesized in a 30-and-3 exercise; Bostrom vs. Boltzmann's 1906 tragedy, XML/XSLT strict ASTs vs. SKILL.md/AGENTS.md variable-ratio B.F. Skinner boxes, warm browser KV-cache reuse across local article boundaries, Neovim Lua 7-bit ASCII purity vs. classic Vim ^M control-byte macros, and log2(N) bisection (auto mechanic to CERN LHC glueball triggers) vs. the "binary search" misnomer articulated; wired classify_markdown_fences(), transform_markdown_glitch_line(), find_next_markdown_glitch(), and fix_markdown_glitches() (<leader>f / \f in Normal and Visual modes) into init.lua (# § THE COPY-BUTTON DELIMITER INVERSION). WITNESSED: MD_GLITCH_TOOL_MISSING -> 11/11 specimen lines healed in operator terminal and live <F2> + \f in journal.txt restoring @Spell spell-checking, Ruff clean, deed qamy.ai_461-236c0a68.zip.
[[[DIVIDER]]]
# --- START RECEIPTS (newest first; cap 20 lines; a line pushed past the cap is deleted, never moved -- git and the rolling pin are the archive) ---
# 2026-10-29 dismount HONEYBOT #TICKER_BAR LED BILLBOARD, IDLE-GATED SPLIT-FLAP TRANSITIONS, AND YTTICKER SIDE-BAND CLI (deeds qamy.ai_462 through qamy.ai_467-e9622f20.zip; pipulate commits c1e0f67, 293a532; Gemini 4 Argon High on every turn): Linux shared-library page caching (obs-studio libQt6*.so Shared_Clean vs. per-process PyQt6 Private_Dirty heap and /nix/store hash skew), X11 _NET_WM_STATE_ABOVE Z-order wars vs. EWMH _NET_WM_STRUT_PARTIAL docks, and autoregressive Context Recapture copy-inertia vs. Landauer's erasure tax and RoPE softmax attention decay analyzed; sliced a 4-row eye-level #ticker_bar widget into remotes/honeybot/scripts/logs.py (SonarApp) reading /tmp/honeybot_ticker.txt via st_mtime polling with a 3-row solid-block (█ ▀ ▄) LED matrix font (LED_FONT_3X3) and remote ytticker CLI (--broadcast ticker, --scroll, --small, --reset) in scripts/articles/common.py and flake.nix; upgraded #ticker_bar to a double-buffered Pinball DMD / Split-Flap Billboard (_rebuild_billboard_cache) holding centered 3-row LED anti-bounce cards (HOLD TIGHT! MAX POPS IN TO SAY HI | LEAVE A COMMENT TO SUMMON THE HUMAN | LIVE AI BOT LOGS * MIKELEV.IN) at 0% CPU for 4.5s (CARD_HOLD_TICKS = 56) and gating its 2-frame vertical split-flap transition on event-loop jitter (_is_window_clear_for_smooth_flip, dt < 0.115s) (# § THE IDLE-GATED SPLIT-FLAP). WITNESSED: LOCAL_LOGS_TICKER/LOCAL_COMMON_TICKER/REMOTE_LOGS_TICKER NO -> YES and LOCAL_BILLBOARD/LOCAL_SCROLL_FLAG/REMOTE_BILLBOARD NO -> YES (0.2768s), stream.py relaunched (pid=2344570) and live vertical split-flap transition witnessed on Honeybot :10.0, Ruff clean, deed qamy.ai_467-e9622f20.zip.
# 2026-10-29 dismount EO 14434 AI-TO-SI REBRAND, ARTIFICE vs. DUCK DECOYS, KANTIAN MARKOV BLANKETS, XSLT vs. SKINNER-BOX VIBE-CODING, AND NEOVIM \F MARKDOWN HYGIENE (deeds qamy.ai_460-3e9ce06c.zip through qamy.ai_461-236c0a68.zip; pipulate commits 5ed37c7, fe5bc6d; Gemini 4 Argon High on every turn): Presidential Executive Order 14434 (Sept 29, 2026, 91 FR 63129) AI -> SI rebrand and NIST Systeme International namespace collision analyzed; Latin ars + facere (PIE *h2r-ti-*) and Dawkins's Extended Phenotype mapped against isoamyl acetate receptor equivalence vs. aggressive mimicry (hunter's duck decoy); Kant's noumenon/phenomenon, von Uexkull's Umwelt, Friston's Markov blankets, von Holst & Mittelstaedt's efference copy / reafference, Norbert Wiener's cybernetics, and Judea Pearl's do(X) straddle actuator synthesized in a 30-and-3 exercise; Bostrom vs. Boltzmann's 1906 tragedy, XML/XSLT strict ASTs vs. SKILL.md/AGENTS.md variable-ratio B.F. Skinner boxes, warm browser KV-cache reuse across local article boundaries, Neovim Lua 7-bit ASCII purity vs. classic Vim ^M control-byte macros, and log2(N) bisection (auto mechanic to CERN LHC glueball triggers) vs. the "binary search" misnomer articulated; wired classify_markdown_fences(), transform_markdown_glitch_line(), find_next_markdown_glitch(), and fix_markdown_glitches() (<leader>f / \f in Normal and Visual modes) into init.lua (# § THE COPY-BUTTON DELIMITER INVERSION). WITNESSED: MD_GLITCH_TOOL_MISSING -> 11/11 specimen lines healed in operator terminal and live <F2> + \f in journal.txt restoring @Spell spell-checking, Ruff clean, deed qamy.ai_461-236c0a68.zip.
[[[REPLACE]]]
Target: foo_files.py
[[[SEARCH]]]
# § THE COPY-BUTTON DELIMITER INVERSION (banked 2026-10-29, deed 461) -- Web chat HTML-to-Markdown copy serializers invert adjacent closing tags (**text \x60code**\x60) and collapse spaced inline-backtick escapes (\x60\x60 \x60 \x60\x60 -> \x60\x60\x60), trapping Neovim's syntax/markdown.vim in unclosed non-@Spell regions; never end a bold or italic span on an inline code boundary or emit literal backtick-escape spans in prose, and use <leader>f (\f in init.lua) to locate and heal cross-nested spans and naked fences.
[[[DIVIDER]]]
# § THE IDLE-GATED SPLIT-FLAP (banked 2026-10-29, deed 467) -- On CPU-constrained broadcast appliances where neural TTS synthesis and SQLite queries periodically starve the UI event loop, default to zero-CPU pre-rendered centered still cards over continuous horizontal scrolling and gate multi-frame transitions on recent frame-time deltas so starvation degrades to an atomic swap rather than visible stutter.
# § THE COPY-BUTTON DELIMITER INVERSION (banked 2026-10-29, deed 461) -- Web chat HTML-to-Markdown copy serializers invert adjacent closing tags (**text \x60code**\x60) and collapse spaced inline-backtick escapes (\x60\x60 \x60 \x60\x60 -> \x60\x60\x60), trapping Neovim's syntax/markdown.vim in unclosed non-@Spell regions; never end a bold or italic span on an inline code boundary or emit literal backtick-escape spans in prose, and use <leader>f (\f in init.lua) to locate and heal cross-nested spans and naked fences.
[[[REPLACE]]]
Target: foo_files.py
[[[SEARCH]]]
# 🚨 PRIORITY 0: BOOT THE CONSULTANCY (REVENUE, LEAD-GEN, & PROOF SURFACES)
# ============================================================================
# - LANDED (2026-10-21, P0.1 PART 1 — 4-CARD LINEAR SVG HORIZON & PROPORTION STRIP, deed 120): Removed static SVG donuts from `_layouts/post.html` and replaced homepage donuts in `publishizer.py`, `_layouts/default.html`, and `index.md` with 4 SQLite-driven linear SVG gauges (`0% -> 20%` RFC 9110 Adoption Horizon, Bimodal JS vs. Markdown split, `🔷` RFC 9421 Signed Hits & Clients, and `🛑` Cloaked vs. `🟠` Authentic Bot Forensics); OWED (Part 2): HTMX/SVG left-right time-slider scatter plot over daily snapshots.
[[[DIVIDER]]]
# 🚨 PRIORITY 0: BOOT THE CONSULTANCY (REVENUE, LEAD-GEN, & PROOF SURFACES)
# ============================================================================
# - LANDED (2026-10-29, P0.17 HONEYBOT #TICKER_BAR LED BILLBOARD & YTTICKER SIDE-BAND CLI, deed 467): Sliced eye-level `#ticker_bar` into `remotes/honeybot/scripts/logs.py` reading `/tmp/honeybot_ticker.txt` with double-buffered 3-row solid-block (`█ ▀ ▄`) LED cards, 4.5s 0%-CPU hold, jitter-gated 2-frame vertical split-flap transitions, and `ytticker` (`--broadcast ticker`, `--scroll`, `--small`, `--reset`) in `scripts/articles/common.py` and `flake.nix`; OWED: upgrade the 3-row LED glyph matrix to a 5-pixel-high Ameritech set-top-box bitmap font (reclaiming the top border row for 5 full glyph rows).
# - LANDED (2026-10-21, P0.1 PART 1 — 4-CARD LINEAR SVG HORIZON & PROPORTION STRIP, deed 120): Removed static SVG donuts from `_layouts/post.html` and replaced homepage donuts in `publishizer.py`, `_layouts/default.html`, and `index.md` with 4 SQLite-driven linear SVG gauges (`0% -> 20%` RFC 9110 Adoption Horizon, Bimodal JS vs. Markdown split, `🔷` RFC 9421 Signed Hits & Clients, and `🛑` Cloaked vs. `🟠` Authentic Bot Forensics); OWED (Part 2): HTMX/SVG left-right time-slider scatter plot over daily snapshots.
[[[REPLACE]]]

! python3 -c 'import pathlib; t = pathlib.Path("remotes/honeybot/scripts/logs.py").read_text(); print("FONT_3X3=" + ("YES" if "LED_FONT_3X3" in t else "NO"), "FONT_5ROW=" + ("YES" if "LED_FONT_5" in t else "NO"))'
remotes/honeybot/scripts/logs.py
scripts/articles/common.py

Why spawn a 60 MB Qt overlay and fight X11 Z-order when a 0 MB Textual HUD panel can run an idle-gated 3-row LED split-flap billboard at 0% CPU?
https://mikelev.in/futureproof/idle-gated-split-flap-led-billboard-textual-ytticker/
#Python #Linux #NixOS

A dramatic widescreen graphic-novel ink-and-wash illustration set inside a deep obsidian-slate (#111111) cybernetic broadcast studio. Vertically centered in the composition is a glowing amber and cyan three-row solid-block LED split-flap billboard module sliced seamlessly across the middle of a dark terminal telemetry console, mid-flip between crisp geometric block glyphs while green and gold server log streams flow above and dual intelligence gauges glow below. Subtle mechanical relay latches and a brass tuning fork beside the console evoke frame-time jitter gating and zero-CPU equilibrium against dark moody studio shadows. Full-bleed edge-to-edge composition filling 100% of the canvas with no borders, no frames, no matting, no margins, and no text overlays or lettering.
